2025
Versys 650
Colours
Editions of Versys 650
- Features
- Technologies
- Specifications
Fun Package on Winding Roads
Offering a unique package comprising long-travel suspension & sporty 17” wheels, a slim, upright riding position and a compact Parallel-Twin engine tuned for low-mid range torque, the Versys 650 was designed to maximize rider enjoyment on the street – especially when the roads get twisty. The addition of rider support technology like KTRC contributes to the high level of rider confidence in a wide range of street-riding situations.
More Comfort and Convenience
Complementing updates to the upper cowl and windshield that offer increased wind protection for greater rider comfort on longer rides, new 4.3” full-colour instrumentation with smartphone connectivity allows riders to connect with their machine like never before, adding to a richer motorcycle lifestyle.
Emotional Design
Like the Versys 1000, the new Versys 650 features an emotional design to charm the rider. The much more flowing styling features a clear line of colour traceable from the front of the bike to the rear. A balanced use of colour and materials emphasizes the functional beauty of the bike’s individual parts and the sculpted bodywork shaped with rider comfort in mind.
TFT Colour Instrumentation with Smartphone Connectivity
The compact new 4.3” all-digital TFT colour instrumentation gives the cockpit a high-tech, highgrade appearance. The new meter also offers additional features unavailable on the previous model, including smartphone connectivity.
Slim, Upright Riding Position
Slim, upright position and wide handlebars offer a naturally relaxed posture and high controllability.
649 cm3 Liquid-Cooled, 4-Stroke Parallel Twin
Optimised for gratifying response in everyday riding situations, the exciting 649 cm3 Parallel Twin engine offers smooth, linear response, strong low-mid range torque and favourable fuel economy.
LED Lightning
Complementing its LED taillight, new LED headlights add symmetry to the Versys 650’s “face.” LED turn signals add a modern touch, contributing to the bike’s good looks.
KTRC (Kawasaki TRaction Control)
Kawasaki's advanced traction control system provides both enhanced sport riding performance and the peace of mind under certain conditions to negotiate low-traction surfaces with confidence. Two modes allow riders to adjust settings to suit the riding situation and rider preference.
Latest Versys Family Styling
Redesigned upper cowl inspired by the Versys 1000 and a new windshield bring the Versys 650 in line with latest Versys family styling.
Long-Travel Suspension and 17” Wheels
The combination of long-travel suspension and sporty 17” wheels enables fun, sporty riding on a wide variety of roads and conditions.
Smartphone Connectivity
Smartphone connectivity contributes to an enhanced motorcycling experience by enabling riders to connect to their motorcycle wirelessly.
Dual Throttle Valves
Dual Throttle Valves offer increased power and greater ease of use care of a second set of ECU-controlled throttle valves.
Economical Riding Indicator
The Economical Riding Indicator is a mark appearing on the instrument panel to indicate favourable fuel consumption, encouraging fuel efficient riding.
ABS
ABS (Anti-lock Brake System) ensures stable braking performance by preventing wheel lock during braking.
Engine
| Engine type | Liquid-cooled, 4-stroke, parallel twin |
|---|---|
| Compression ratio | 10.8:1 |
| Valve system | DOHC, 8 valves |
| Bore x stroke | 83.0 x 60.0 mm |
| Displacement | 649 cm³ |
| Fuel system | Fuel injection: 38 mm x 2 |
| Lubrication | Forced lubrication, semi‑dry sump |
| Starting System | Electric |
| Ignition System | Digital |
Performance & Transmission
| Maximum power | 49.0 kW {67 PS} / 8,500 rpm |
|---|---|
| Maximum torque | 61.0 N•m {6.2 kgf•m} / 7,000 rpm |
| CO2 emission | 107.0 g/km |
| Fuel consumption | 4.4 l/100km |
| CO2 emission 35 kW kit | 107.0 g/km |
| Fuel consumption 35 kW kit | 4.5 l/100km |
| Transmission | 6-speed, return shift |
| Clutch | Wet, multi disc |
| Primary Reduction Ratio | 2.095 (88/42) |
| Gear Ratios 1st | 2.438 (39/16) |
| Gear Ratios 2nd | 1.714 (36/21) |
| Gear Ratios 3rd | 1.333 (32/24) |
| Gear Ratios 4th | 1.111 (30/27) |
| Gear Ratios 5th | 0.966 (28/29) |
| Gear Ratios 6th | 0.852 (23/27) |
| Final drive | Sealed chain |
| Final reduction ratio | 3.067 (46/15) |
Frame & Dimensions
| Frame type | Tubular diamond, high-tensile steel |
|---|---|
| Rake | 25.0 ° |
| Trail | 108 mm |
| Wheel travel front | 150 mm |
| Wheel travel rear | 145 mm |
| Tyre, front | 120/70 ZR17 M/C (58W) |
| Tyre, rear | 160/60 ZR17 M/C (69W) |
| L x W x H | 2,165 x 840 x 1,360 mm |
| Steering angle L/R | 35° / 35° |
| Wheelbase | 1,415 mm |
| Ground clearance | 170 mm |
| Fuel capacity | 21.0 liter |
| Seat height | 845 mm |
| Curb mass* | 219 kg |
| | *Curb mass includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied). |
| Estimated dry weight** | 200 kg |
| | **Estimated Dry weight does not include all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied). |
Brakes & Suspension
| Brakes, front | Dual semi-floating petal discs |
|---|---|
| Front Brake Diameter | Ø 300 mm |
| Front brake caliper type | Dual-piston |
| Brakes, rear | Single petal disc |
| Rear Brake Diameter | Ø 250 mm |
| Rear brake caliper type | Single-piston |
| Suspension, front | Inverted fork with adjustable rebound damping (right side), and spring preload adjustability (left side) |
| Front suspension diameter | Ø 41 mm |
| Suspension, rear | Laydown offset single-shock with remote spring preload adjustability |
Accessories
LED Fog Light Kit
Rugged and aerodynamic dual LED Light Bar provides additional lighting for improved visibility.
- Integrates into the front headlight area
- Reflector Facing Technology (RFT) allows for optimum LED output while consuming far less power than conventional LED or halogen bulbs
- Steel bracket with high-impact plastic light housings
- Dealer installation recommended
Top Case (40L)
Durable ABS construction 40L top case, lockable with quick-release base. Fits one full face helmet, size large. Requires top case cover, fitting kit , and lock cylinder set. (Sold separately)
Frame Sliders
Help protect your vehicle’s bodywork with a Frame Slider Set.
- Slide pads are made from polyurethane plastic for increased durability
- Chassis mounted brackets have been factory tested and approved for dispersion of impact during vehicle tip-overs
- Dealer installation recommended
- Note: Frame Sliders help protect your motorcycle, but will not prevent all types of damage
Pannier Set (2 X 28L)
Quick release 56L pannier set that will hold most full-face helmets. Panniers designed to attached to handgrips and footrest and give a clean sporty look when removed. Narrow mounting width of 93cm and suitable for high speed
cruising.
Required additional components (not included):
- Pannier fitting kit
- Pannier cover set
- Pannier deco stripe set
- Pannier lock cylinder set
Top Case (47L) Inner Bag
Rigid, water-resistant bag with compartments makes it easy to pack your cargo and drop into the locking Top Case. Once you have arrived at your destination, just grab your packed Inner Bag so you can leave the Top Case on your motorcycle and get going.
- Nylon construction with reflective piping
- Purchase as an optional component of the Top Case (47L), sold separately
Pannier Inner Bag Set (2 x 28L)
Zippered black nylon liners make it easy to pack your cargo and drop into the locking panniers.
Once you’ve arrived at your destination, just grab your pannier inner bags so you can leave the panniers on your motorcycle and get going.
- Left and right liner
- Purchase as an optional component of the 28L Panniers, sold separately
Top Case (47L)
Keep your personal items in 47 liters of lockable, waterproof storage; enough room for two full-face helmets. Requires Base Plate and model specific accessories.
- Kawasaki’s One Key System allows you to key the lock to your ignition key – refer to the letter on your key to determine if your need a Type A or Type B system.
- Kawasaki logos and factory-matched trim give your bike a customized look
- Constructed of molded ABS plastic
- Requires Carrier Plate, Color Panel, Deco Plate, and One Key System all sold separately
- Dimensions 432mm (17”) L x 584mm (23”) W x 305mm (12”) H
- Top Case load limit is 5kg (11 lbs.)
- On the Ninja 1000 SX, the Top Case (47L) is not compatible with panniers.
- USB Socket
- One-Key System Helmet Lock
- Tank Pad
- Handguard Set (Versys 650)
- Top case (40L) fitting kit, black
- LED Fog Light Kit
- Top case (40L) cover, Metallic Spark Black (660)
- Underseat Bracket for U-Lock
- 12V DC Power Socket
- Relay Kit
- High Windscreen Bracket Kit
- Heated Grip Set
- Top Case (40L)
- Frame Sliders
- GPS Bracket
- Top Case Lock Cylinder Set
- Pannier Lock Cylinder Set (Inner Groove)
- Top Case (47L) Bracket
- Pannier Set (2 X 28L)
- Top Case (47L) Inner Bag
- Pannier Inner Bag Set (2 x 28L)
- Top Case (47L) Backrest Pad
- Dashboard Screen Protector
- Top Case (47L) Base Plate
- Top Case (47L)
